HS3030P


	The HS3030P kit consists of:
		HS3000	Pre-amplifier x 2
		HS30	Detachable hyper-cardioid capsule x 2
		HSstudio	Plastic studio "click closed" case
	Accessories
		HSmc	Microphone clip
		HSavm	Anti-vibration mount
		HSflightP	Lockable metal flightcase
	Also Available:
		HS10	Omni-Directional capsule
		HS20	Cardioid capsule
		HS40	Sub-cardioid capsule
hyper-cardioid studio condenser microphone

	Sensitivity:	-32dBv/Pa (nominal)
	Polar Pattern:	Hyper-cardioid

		Click here for full spec sheet


	General Specification
	System:		Detachable capsule
	Frequency response:		20Hz - 20kHz (pre-amp 20Hz - 100kHz)
	Max output @1kHz:*		+4dBv; 135dB SPL. (-2dBv; 129dB SPL)
	Self noise:		~17dBA
	Impedance:		<600ohms
	Connector:		3 pin gold plated male XLR
	Power:		12-48v Phantom power
	Output:		Electronically balanced
	Dimensions:		160mm x 23mm dia
			Pre-amp 132 x 23 dia; capsule 35 x 23 dia
	Weight:		290g (pre-amp 265g; capsule 25g)
	* max output reduced at 12v.
